Freedom Won LiTE Home 15/12 HV

The Freedom Won LiTE Home 15/12 HV LiFePO4 battery is a high-quality energy storage solution designed for both residential and industrial solar applications. Let’s explore its key specifications:

• Total Energy Capacity: 15 kWh
• Energy Available at 80% Depth of Discharge (DoD): 12 kWh
• Energy Available at 90% Depth of Discharge (DoD): 13.5 kWh
• Max & Continuous Discharge Current:
  • Max: 150 A
  • Continuous: 80 A
  • Max & Continuous Discharge Power: 20 kW / 12 kW
• Max & Continuous Charge Current: 100 A
• Nominal Voltage: 153 V
• Max/Min Operating Voltage: 170 V / 137 V
• Battery Dimensions (H x W x D): 745 mm x 490 mm x 290 mm
• Battery Weight: 130 kg
• DC Connection: Fly Leads (1x16 mm² per electrode)
• Enclosure: Aluminum enclosure painted white, suitable for indoor use or fully protected under-cover environments (rated to IP20)
• Protection: Shunt Trip Circuit Breaker sized to suit max current, can be tripped by BMS if critical fault (includes overcurrent, cell under and over voltage, temperature, weak cell detection, and minimum State of Charge control)
• Control Interface: CAN Bus for diagnostics & troubleshooting, RJ45 strictly for BMS & inverter communication
• Human Interface: State of Charge display (0 to 100%), Error light, Error Reset button, USB plug for programming
• Warranty: 10 years or 4,000 cycles for average 80% DoD, and max 90% DoD
• Expected Service Life: 10 years (or 4,000 cycles) warranty for 80% average DoD, 13-15 years (>5,500 cycles) expected life at 70% DoD, 15-20 years at 50% DoD (>7,000 cycles)

The Freedom Won LiTE Home 15/12 HV battery is compatible with most inverters on the market and supports high charge and discharge currents.
